BC5070 Small Square Baler

GROMMET, 34.9mm ID x 50.8mm OD x 9.5mm Thk

TERMINAL CONNECTOR, 10 - 12 GA

SPRING CLIP

BULB, 12V, 10W

REFLECTOR, 80mm OD, Orange

CARRIAGE BOLT, Short Nk, 3/8'' - 16 x 1'', Gr 5

BOLT, 1/2''-13 x 1-3/4'', Gr 5

NUT, M8 x 1.25, Cl 8

BELLEVILLE WASHER, M6 Bolt Size x 14mm OD x 1.3mm Thk

FINGER, Right Hand Optional Teardrop Feeder Finger

ELEC CONNECTOR, Male, 6 Pole

CARRIAGE BOLT, M10 x 1.5 x 30mm, Cl 8.8

BOLT, Hex, M8 x 1.25 x 20mm, Cl 8.8

WASHER, 0.81'' ID x 1.47'' OD x 0.13'' Thk

CLAMP, 23.8mm, Coat, 10.3mm Bolt Hole, P Type

SPRING

CARRIAGE BOLT, M10 x 20mm, Cl 8.8

NUT, Hex, M6 x 1 pitch, Cl 8

BRACKET

RETAINER COLLAR, 34.92mm ID x 56.33mm OD x 17.46mm Thk

CARRIAGE BOLT, M8 x 1.25 x 20mm, Cl 8.8

WASHER, Flat, 5.3mm ID x 10mm OD x 1mm Thk,

CLEVIS PIN

WIRE HARNESS, Rear Wire Harness

HUB, 6-Bolt Right Hand Wheel Hub - 1.5" ID x 7.25" OD

BULB, 12V, 10W

SHIELD

BELLEVILLE WASHER, M8 Bolt Size x 18mm OD x 1.4mm Thk

NUT, M10 x 1.5, Cl 8

CARRIAGE BOLT, M10 x 20mm, Cl 8.8

BOLT, Hex, 1/2'' - 20 x 13/16'' Gr 5

BALL BEARING, YET 207-106WU - 35 mm ID x 72 mm OD x 25 mm W

SEAL, 44.45mm ID x 69.19mm OD x 10.72mm Thk

CARRIAGE BOLT, M8 x 1.25 x 20mm, Cl 8.8

SHAFT

LOCK WASHER, 3/8 0.381 CST ZND

BELLEVILLE WASHER, M6 Bolt Size x 14mm OD x 1.3mm Thk

LINK CHAIN

SLOTTED NUT, M20 x 1.5, Cl 04

HANDLE

BELLEVILLE WASHER, 10mm ID x 22mm OD x 1.6mm Thk

BULB, 12V, 10W

WIRE CLAMP, J

DECAL, Tape, Yellow Reflective

RETAINER COLLAR, 34.92mm ID x 56.33mm OD x 17.46mm Thk

WASHER, 13.1mm ID x 25.4mm OD x 3.68mm Thk

SHAFT

SHEAR BOLT
